Bendpak Telescopic Arm Kit for Mobi-EVS Electric-Hydraulic Lift Tables

Description

EV battery pack drops on wet service bays demand precise structural support. The Bendpak Telescopic Arm Kit Mobi-EVS converts flat lift tables into multi-point chassis adapters to cradle complex subframes. It supports heavy modular components, though low-clearance sports cars require careful pre-positioning before rolling the table under lift points.

Solid high-tensile structural steel plates form the base slide brackets while heat-treated rectangular box tubing houses the extendable arms. Designed to mount onto Mobi-EVS lift tables, the four arms together handle 4,000 lbs of distributed payload weight. The unboxed arm kit weighs 112 lbs, expanding the table reach across a working stance measuring 48in wide by 62in long. Zinc plating stops corrosion from road brine.

Key Features of Bendpak 5210454

Dealership technicians buy Bendpak 5210454 arm kits to drop electric vehicle battery enclosures without vehicle frame contact. The modular tooling speeds up powertrain swaps and EV drivetrain maintenance.

• Four telescoping steel arms extend outward to match irregular EV battery pack bolt holes.
• Screw pads provide 2-1/2in of vertical height adjustment to level uneven structural castings.
• Recessed slide channels lock into the perimeter slots of Mobi-EVS lift tables.
• Heavy detent pins secure arm extension lengths against shifting during powertrain transport.
• Durable polyurethane pad inserts protect expensive aluminum battery cases from metal-on-metal gouging.
• The 4,000 lbs working capacity holds massive electric truck battery enclosures.
• Modular bracket design allows fast arm removal when returning the lift to a flat table.

Bench Load Deflection Testing

Physical deflection testing under 1,000 lbs load per arm shows less than 0.040in vertical flex at maximum 18in outer extension. Threaded support pads hold 2,500 lbs static axial force without thread jump or runout deviation. Arm slide mechanisms retain smooth adjustment travel under 250 lbs side shear load. The zinc-dichromate coating resists 240 hours of salt spray exposure without surface rust. The steel locking detents maintain solid mechanical engagement under 300 lbs of lateral shock loading.

Shop Handling Maintenance Protocol

Telescoping arm sleeves slide with 12 lbs hand pull force when clean. Do not buy this arm kit for unrated generic scissor carts or standalone vehicle lifting without an approved Mobi-EVS table base.

• Wipe arm sliding tubes clean and apply light dry PTFE lubricant every 40 hours of use.
• Inspect screw pad acme threads and pack with NLGI 2 grease every 30 days.
• Torque table mounting bracket hardware to 65 ft-lbs every 6 months to maintain rigid alignment.

Warranty Coverage Crate Manifest

Bendpak backs this commercial adapter kit with a 1-Year structural warranty covering metal components. The unboxed crate package contains four telescoping steel arms, four threaded screw adapter pads, four polyurethane contact blocks, table mounting slider hardware, and a certified load rating manual.
