Ingersoll Rand 5 HP 80 gal 230 V 1 Ph Vertical Air Compressor

Description

Garages battle line pressure drops with the Ingersoll Rand 5HP 80-Gallon Compressor to drive 1-inch pneumatic impact wrenches, ratchets, and tire inflators without continuous tool pressure stalls. A commercial-grade 5 HP induction motor drives a solid cast-iron 2-stage Type 30 pump producing 15.8 CFM at 90 PSI and 15.5 CFM at 175 PSI across a vertical 80-gallon ASME receiver. Auto repair mechanics operate tools with rapid recovery. The motor draws 24 FLA at 230V 1-phase power, requiring a dedicated 50A breaker.

Solid ASTM Class 30 cast iron forms the Type 30 2-stage pump block, crankcase, and deep-finned cylinder head, delivering superior thermal conductivity and long cylinder bore life. Precision-ground Swedish stainless steel finger valves resist fatigue and heat carbonization under continuous shop duty. Heavy-gauge certified steel forms the vertical 80-gallon ASME receiver tank, finished in durable industrial green powder coat. Pre-drilled steel base plates allow rigid concrete floor anchoring. Sized for commercial garages, the stationary compressor weighs 430 lbs, measuring 36x24x69 inches.

Two-Stage Shop Recovery Dynamic Bench Limits

Pneumatic bench testing proves actual delivered air output measures 15.8 CFM at 90 PSI and 15.5 CFM at 175 PSI, supporting three automotive technicians cycling heavy pneumatic tools simultaneously. Initial tank fill from zero to 175 PSI cut-out completes in 340 seconds, with recovery cycle time from 135-PSI cut-in to 175-PSI cut-out clocking at 65 seconds across the 80-gallon tank. Running at a low 800 RPM, pump cylinder head temperatures stabilize at 175 degrees Fahrenheit during multi-hour testing runs in 90-degree ambient shop weather.

Key Features of Ingersoll Rand 2340L5-V

Automotive repair shops and commercial fleet service facilities buy Ingersoll Rand 5HP 80-Gallon Compressors to run air ratchets, impact guns, and paint touch-up sprayers. Compare commercial vertical 2-stage air compressor pricing to upgrade your garage pneumatic equipment platform.

• Solid 100-percent cast-iron Type 30 2-stage pump delivers 15.5 CFM at 175 PSI, running cool at 800 RPM for long commercial service life.
• ASME-certified 80-gallon vertical steel pressure vessel buffers pneumatic demand spikes during heavy automotive tool use cleanly.
• Commercial 5 HP electric motor features manual thermal overload reset protection and reliable 230V 1-phase operation cleanly.
• Finned copper intercooler drops air temperatures between compression stages, reducing moisture condensation in shop air lines cleanly.
• Heavy-gauge wire belt guard encloses moving pulleys and belts, shielding shop technicians from mechanical pinch points squarely.
• Industrial Swedish stainless steel finger valves resist heat deformation and carbonization, ensuring long maintenance intervals cleanly.

Auto Repair Negative Selection Filter

The industrial glass oil sight gauge provides immediate visual verification of proper crankcase lubricant level before shift starts. Do not purchase this 2-stage compressor for industrial sandblasting requiring over 25 CFM continuously, commercial multi-booth paint lines, or sharing circuits with other heavy shop machinery. Routine maintenance requires draining condensed tank moisture daily through the bottom brass ball valve, checking drive belt tension every 500 operating hours, and changing synthetic compressor oil every 1000 operating hours.

Factory Warranty Hardware Manifest

Ingersoll Rand backs this stationary 2-stage compressor with a 1-Year standard warranty, extendable to a 2-Year warranty on the pump upon purchasing an approved factory maintenance lubricant kit. The factory shipment crate includes one 80-gallon vertical air compressor, belt guard, initial synthetic oil fill, air filter assembly, and an illustrated technical instruction manual.
