Erin Rope Composite Double Braid Pulling Rope 9/16 X 600′

Description

Cable snap hazards and high friction resistance inside long conduit runs stall commercial electrical installations. The Erin Rope Composite Double Braid pulling rope delivers 9000 lbs of breaking strength across a 600-foot continuous spool. It feeds tugger winches fast, though pulling across sharp unreamed conduit burrs demands protective cable guide rollers.

Erin Rope braids the inner load-bearing core from high-tenacity composite fibers, jacketed with a double-braided polyester outer sheath. The 9/16-inch diameter construction balances high breaking strength with low friction resistance inside 2-inch to 4-inch conduit pipes. Factory-spliced pulling eyes on both ends connect directly to cable pulling grips and swivels. Total 600-foot spool weight registers at 62 lbs on heavy wooden transport reels.

Features of Erin 9/16in Rope

Commercial electrical contractors, utility installers, and industrial plant electricians demand high tensile strength, minimal elongation, and smooth capstan feed. Master electricians route this composite pulling rope through underground duct banks, branch raceways, and commercial feeder conduit.

• 9000-lb certified average breaking strength pulls commercial copper feeders and branch circuits.
• 600-foot continuous single-spool length handles standard commercial conduit runs without intermediate splices.
• Composite double-braid construction combines low stretch core fibers with an abrasion-resistant outer jacket.
• Low elongation profile prevents snap-back recoil energy in the event of accidental cable binding.
• Factory-spliced pulling eyes on both ends provide instant connection to cable pulling grips and swivels.
• Smooth exterior braid reduces pulling friction and prevents heat buildup over capstan winch drums.
• Resistance to moisture, rot, and electrical conduit lubricants ensures long service life across seasons.

Tensile Bench Proof Load Telemetry

Tensile break testing certified ultimate tensile strength at 9400 lbs on a calibrated hydraulic rope pull test bed. Composite core fibers showed less than 3.5 percent stretch under full 1800-lb working load limit pulling tension. Drum friction rub testing showed zero outer jacket strand separation after sixty minutes of continuous capstan winch wrapping at 50 FPM. Internal fiber core temperatures rose 14°F above ambient room temperatures during heavy conduit pulling runs. Spool payout drag measured zero across wooden transport flanges.

Jobsite Rigging Realities Maintenance Directives

The flexible double-braid jacket feeds smoothly onto motorized capstan winch drums without hockling or kinking. This synthetic pulling rope is not built for permanent overhead hoist suspension, vehicle recovery winching, or lifting personnel.

• Outer braided jackets demand tactile inspection for strand cuts, excessive fuzzing, and chemical contamination.
• Spliced pulling eye thimbles require inspection for stitch separation and metal eye distortion every pull.
• Ropes exposed to underground mud or grit require freshwater rinse and air drying before spool storage.

Certified Industrial Warranty Reel Manifest

Erin Rope backs this composite pulling rope with a 1-Year commercial warranty package covering braid integrity and core material defects. The factory wooden reel manifest contains the 600-foot spool of 9/16-inch composite pulling rope, factory test certificate, and official cable pulling safety documentation.
