Greenlee Slug Splitter 1/2 Inch to 2 Inch Conduit Punch Set

Description

Tired of shattered punch dies and jammed metal slugs when punching conduit holes through tough ten-gauge stainless steel? The Greenlee 7506 Slug Splitter Set shears stainless steel cleanly from half-inch to two-inch trade sizes. It requires a hydraulic knockout ram or manual driver, demanding correct draw stud lubrication to avoid thread galling under high tonnage.

Hardened tool steel constructs all six matched punch cutters and die cups, heat-treated to resist chipping under severe ten-gauge stainless steel cutting loads. The passive punch set draws zero electrical power on its own, utilizing hydraulic ram downforce to shear steel slugs. Total dry bare kit weight measures 10.5 lbs. The set covers half-inch through two-inch conduit sizes inside a heavy plastic carrying case.

Key Features of Greenlee 7506

Industrial electrical contractors buy Greenlee 7506 Slug Splitter sets to punch clean conduit holes through stainless steel control boxes and food-grade enclosures. Equipment pricing delivers heavy-duty tool steel dies engineered to split ten-gauge stainless steel without dulling or edge chipping.

• Self-centering punch geometries split stainless steel slugs in half for fast drop-out from die cups.
• Hardened tool steel dies punch through ten-gauge stainless steel, brass, aluminum, and fiberglass enclosures.
• Universal draw stud threading fits Greenlee hydraulic hand pumps, foot pumps, and battery knockout drivers.
• Smooth shearing action creates clean round holes without metal distortion or burrs on panel walls.
• Laser-marked size markings on punches and dies allow fast identification in crowded service toolboxes.
• Hex-head drive studs allow hand ratchet operation when hydraulic power pumps are unavailable on site.
• Heavy blow-molded plastic storage cases keep matched punches, dies, and draw studs organized between jobs.

Stainless Punching Tonnage Bench Metrics

Hydraulic bench evaluations on ten-gauge 304 stainless steel confirm the two-inch Slug Splitter punch shearing through at 7,500 PSI ram pressure. The two-point cutting face splits the slug in half, dropping pieces from the die cup without prying tools. Hardness testing confirms punch teeth at 61 HRC, showing zero edge chipping or rounding after forty consecutive stainless steel test punches. Hole roundness tolerances hold within 0.003 inches, producing clean margins that seat water-tight conduit hubs flush.

Stainless Enclosure Usability Realities Maintenance

Threading these heavy dies onto draw studs takes one worker inside commercial enclosure panels. The self-centering punch aligns inside the pilot hole, eliminating off-center hole cuts. Do not buy this punch set for structural steel I-beams, hardened plate armor, or un-drilled panels without pilot holes.

• Coat draw stud threads with high-pressure anti-seize lubricant before every stainless steel punch.
• Wipe metal shavings and cutting oil off the punch cutting edges after each deployment.
• Inspect the cutting teeth for micro-chipping after punching heavy ten-gauge stainless steel panels.

Factory Warranty Manifest Inclusions

Greenlee covers this Slug Splitter punch set with a Lifetime manufacturer warranty against material defects and punch cracking. The heavy blow-molded plastic case contains six matched punch and die sets from 1/2-inch to 2-inch, two draw studs, spacer bushings, and an illustrated operations manual.
